Party on the right business on the left. This rainy day's fun so far.
#calculix #PrePoMax #BillMcClintock #MulletPC

I done did some FEA! You know its good because there's a rainbow of colours.
This is only a test to see if I can remotely operate the software and yes I can. Win!
#FEA #Calculix #PrePoMax #Engineering #FOSS #EngineerForHireAt$1000000PerHour

FreeCAD/Calculix Tutorial and other Tutorials for FEM

http://laurencemarks.co.uk/resources

#FreeCAD @FreeCAD #calculix
(image by laurencemarks)

Did someone of you #engineersofmastodon working with #CalculiX give https://prepomax.fs.um.si/ a try?

#CalculiX 2.21 released: http://www.calculix.de/
Release notes: http://dhondt.de/new_calc.htm
Download binary for Linux (or build it from source): http://dhondt.de/
:freecad: #FreeCAD's FEM Workbench uses CalculiX as a finite-element analysis solver: https://wiki.freecad.org/FEM_CalculiX
💡 #2d #3d #cad #fem #fea #fc3d #diy #engineering

Version 2.21 of #FreeSoftware #CalculiX for 3D Structural Finite Element analysis is out! Check it out! http://dhondt.de/

#opensource #openbim

booya! i got my bikerack topology! thanks to this project called #beso: https://github.com/calculix/beso used #calculix and their #freecad itegration for the first time today. look at this beautiful optimization GIF!

#FreeCAD's HarryvL has added the (WIP) #FEM/#FEA critical plastic strain ratio as a post-processing step for #CalculiX results. This is available from the #VTK pipeline + for export to #ParaView.
https://forum.freecadweb.org/viewtopic.php?p=623785#p623785 #MadeWithFreeCAD #fc3d #FLOSS #FOSS #OpenSource #CAD #MCAD

#FreeCAD #FEM/#FEA workbench is getting some multi-threading love. Specifically #CalculiX anf #Elmer solvers. Thank you 'donovaly' 🙏

https://github.com/FreeCAD/FreeCAD/pull/7158
https://github.com/FreeCAD/FreeCAD/pull/7159

FrontISTR_ posting on the #FreeCAD forum some benchmark #FEM tests between #CalculiX and FrontISTR solver variations.

https://forum.freecadweb.org/viewtopic.php?f=9&t=58019&p=506799#p506794

#buonazione di oggi: convincere uno studente ad usare #Calculix e #freecad anziché piratare abaqus

#FreeCAD #FEM #CalculiX ccx
The script now also supports debian 10.4 :debian: and centos 7 :centos:
https://gitlab.com/PrzemoF/calculix-build-script/

#FreeCAD #FEM #CalculiX ccx 2.16 easy build script now supports fedora 32 :fedora: manjaro 20.0.1 :manjaro: mint 19.3 :linuxmintalt:
https://gitlab.com/PrzemoF/calculix-build-script/
