Got time measurements working via manual cursors. Problem was in Stop Comparator card. Did a swap for now, but suspect Q54, will do component level troubleshooting next, but for now happy to get this closer to working.
0% zone still not working, which means no voltage measurements, and thus no automatic risetime measurements; that’s next on the list.
#tektronix #1960s #oscilloscope #electronics #testEquipment #retroTech

An analog sampling cathode ray oscilloscope with a Nixie tube readout displaying the frequency of the waveform.

Next on the bench, the Tektronix 567 oscilloscope with possibly the first digital readout facility on any oscilloscope.
Swapping a bad tube in the regulator got all the rails up to spec. A few bad Nixie tubes in the readout unit were swapped, and now the real troubleshooting begins.
#tektronix #tek567 #oscilloscope #1960s #electronics #testEquipment #retroTech

This was an easy win. Pulse generator initially had a slow rise time. Some disassembly, cleaning and reassembling got it working properly.
#tektronix #1960s #electronics #testEquipment #retroTech

A 1960s time domain reflectometer on a bench. The instrument is silver with red and black knobs, with a CRT display showing the response of a pulse being sent into an unterminated cable and reflecting back.
