Always print your PCB layout on paper before sending to the manufacturing house
.
#pcb #design #printout #error

Replica of the Elektor power supply LPS1 from 1975 is working😊
.
#replica #elektor #powersupply #lps1 #prototype #electronics #workshop #maker #diy

New Maker project - 555BusDuino for education
.
Arduino Bus System - Breadboard compatible
.
#Arduino #555busduino #atmega328 #uno #electronics #education #workshop #maker #diy

New Maker project - 555BusDuino for education
.
Stackable Arduino Bus System
.
#Arduino #555busduino #atmega328 #uno #electronics #education #workshop #maker #diy

Launch of the new Arduino UNO R4.
.
The Arduino Team just presented the new UNO R4 and his brother UNO R4 Wifi
.
#arduino #uno #r4 #renesas #wifi #microcontroller #learning #makercommunity #electronics #workshop #maker #diy

I always print the PCB Layout on paper before ordering the PCBs
.
You can save a lot of money and time 😊
.
#pcb #renesas #mcu #board #electronics #workshop #maker #diy

I need water!
.
DIY LoRa sensor in action - soil moisture sensor
.
#sensor #node #lora #868mhz #soil #moisture #electronics #workshop #maker #diy

LoRa Server with RFM95W Transceiver
.
Receiving sensor data from sensors in and around the house.
.
#lora #server #868MHz #prototype #sensor #node #electronics #workshop #maker #diy

LoRa Sensor Board with XIAO RP2040 and RFM95W
.
#seeedstudio
#sensor #node #lora #prototype #seeedstudio #xiao #rp2040 #electronics #workshop #maker #diy

@TerrorBite @rc2014 With my own PCBs I dont have to order the kits and have always boards in my workshop.

@TerrorBite @rc2014 I just built the first modules according the original circuit diagram.

I am building and testing a RC2014 computer system
.
@rc2014
#pcb #prototype #z80 #cpu #board #retro #rc2014 #electronics #workshop #maker #diy

Building RFBoard

RFBoard - Arduino Uno with onboard 433 MHz transceiver RFM12B
.
@arduino
#rfboard #rfm12b #433mhz #uno #atmega #microchip #atmega328 #arduino #electronics #workshop #maker #diy

I built a keyboard for the RC2014 modular computer
.
@oldbytes.space
#pcb #prototype #keyboard #z80 #cpu #board #retro #rc2014 #electronics #workshop #maker #diy

Make your own Arduino UNO
Our swiss maker community created an own Arduino Board a couple years ago.
.
Helvetino
.
https://playground.boxtec.ch/doku.php/products/helvetino
.
@arduino
#pcb #makearduino #uno #atmega #microchip #atmega328 #arduino #electronics #workshop #maker #diy

I have my own Make Arduino Kit
.
Make 555Duino with ATmega328
.
@arduino
#pcb #makearduino #uno #atmega #microchip #atmega328 #arduino #electronics #workshop #maker #diy

Retro IC - Opamp 741 from 1980
.
#retro #opamp #ic #component #analog #maker #electronics #diy

PCB with onboard circuit diagram
.
Adjustable voltage reference - 0 to 9.99V
.
#voltage #reference #opamp #ic #component #analog #board #pcb #maker #electronics #diy
