Want to help build a crowdsourced microcontroller?

You're invited to design peripherals (UARTs, timers, synths, etc.) for a
@risc_v chip that will be fabbed for real!

Take part for free!

https://tinytapeout.com/competitions/risc-v-peripheral/

still being young and wild, I experiment with new things.
here I'll try to use the reverse polarity protection diodes marked in green in my next #eurorack project to serve a second purpose as mechanical guides for the power connector.

if it works out well, this can almost be reused like a macro in future eurorack designs.

A few years back I did some reverse engineering on the original Alesis MIDIVerb. I've released the design materials and source code that came out of that effort here: https://github.com/emeb/MIDIVerb_RE

this is really good news for me, the roundtrip latency of my "wenzellabs your'o rack yADDA" is around 5.0ms.

#eurorack #yADDA

#Debian #Linux :ablobcatwave:

@LaF0rge many thanks for dfu-util.

<3

#XMOS works out of the box.

einfachmalso

hey @adafruit I am gonna buy this. but I am gonna write them datasheet myself.

#adafruit
5434

https://cdn-shop.adafruit.com/product-files/5434/C17220-001+datasheet.pdf

yeah right, digikey. but my NAS won't fit in your textbox...

"Bitte geben Sie alle verfügbaren Informationen im Zusammenhang mit der Verwendung an."

#digikey

Feel free to get in touch with my Bruckner Remix. 2 videos - a clip and a summary. enjoy! #video #antonbruckner #bruckner https://www.base.at/dorninger/video-bruckner-remixed-in-space

I love those hacks, just use the PCB material, it's there, it's not just for electronics. I had done this often, even as a child I had developed film roll negatives on copper of PCBs.

On a board I just design, I intend to use two large reverse polarity protection diodes as mechanical guides for an IDC connector that the user puts on my #eurorack board.

https://hackaday.com/2025/07/04/smd-capacitor-doubles-as-cheap-sd-card-latch/

And of course those Nixie tube numbers are screaming to be a clock. The board is a metro esp32-s3 and I’m using the world time API to easily get the time

@LaF0rge obviously plug in that heart shaped USB-stick first, that keeps the screensaver from kicking in...

https://github.com/wenzellabs/LIEBE

listen to all of your lights!

https://github.com/wenzellabs/KIKLOP

#eurorack #KIKLOP

next interesting product from Raspberry Pi: RM2

a standalone BT/WiFi radio - seems they were listening to their customers.

https://www.raspberrypi.com/news/raspberry-pi-radio-module-2-available-now-at-4/

datasheet: https://datasheets.raspberrypi.com/rm2/rm2-datasheet.pdf

#RM2 #raspberrypi #raspberry

I am very much honored that the NSA selector - my very first eurorack module - is now available through modularaddict!

https://modularaddict.com/nsa-selector-full-kit-wenzel-labs

#eurorack #theNSAselector #modular #modularaddict

https://bsky.app/profile/richardoliver.bsky.social/post/3lpokhiqjic2m

👌 😍 👍

oh, I made quite some news in china. not even only AI generated. no orders yet though.

https://news.miracleplus.com/share_link/72113

🌕 GitHub - wenzellabs/the_NSA_selector：NSA 監聽模組
➤ 將網路流量轉化為音訊的 Eurorack 模組
✤ https://github.com/wenzellabs/the_NSA_selector
這個 GitHub 倉庫展示了 wenzellabs 開發的「NSA selector」Eurorack 模組，它能將網路流量轉換成音訊信號。該模組並非音訊介面，而是直接截取網路封包，並將其轉換成音訊輸出。使用者可以透過分析音訊信號來觀察網路活動，例如圖像傳輸、網路延遲，甚至利用未加密的流量來解讀資料。模組本身是一個 100Mbps 的快速以太網路交換器，並將網路流量經過數位類比轉換器和低通濾波器輸出的。
+ 這個模組的概念太酷了！可以把網路流量變成聲音，感覺像是間諜電影裡的工具。
+ 雖然功能有點小眾，但對於對網路安全和音訊實驗感興趣的人來說，這絕對是一個很有趣的工具。
#硬體 #網路 #音訊 #安全

@GripNews ❤️

first learning about UAC2 (USB audio class 2.0) is that it screams for UAC3 (in 7.1).
