This video showcase the animation of assembling Kenworth truck using Blender and eevee as a render engine,
The background or warehouse is also made in blender using pbr and blender shaders
#blender #blender3d #animation #truck #kenworth #technology #tech #solidworks #maya #cinema4d #houdini #nuke #3danimation #blenderanimation #b3d #assembly #designer #mechnicalengineering #mechanical #mechanic #engine #tyre

2025-05-12

I’ve had an annoying issue with #SolidWorks DXF exports at work for a long time. For multi-sheet drawings, each sheet gets its own file (which is desired), and the file name is of the format:

[two-digit number that is sheet number -1]_DrawingFileName.dxf

For example: Sheet 2 of a drawing called Bracket would be:

01_Bracket.dxf

What I really want is: Bracket_Sheet_2.dxf

From a programming standpoint, I understand why the default naming exists. Our fabrication vendors, not so much… I usually manually rename each file accordingly, but that is time-consuming and error prone when you have large numbers of files to deal with on a given project.

I’ve been meaning to write a #Python script to automatically rename all of the DXF files in a given folder based on my desired naming scheme, and I knew it wouldn’t be difficult. I just didn’t expect it to be under 10 lines of code…

I’m sure all the professional programmers are rolling their eyes at how trivial this is, but the point of #programming, and #engineering in general, is to solve whatever problem is in front of you.
