Here is an entire post typed on my very own #handwired split #keyboard! It's not finished, but all letter keys are now working.

The biggest challenge for me now is to figure out how to wire everything together inside the enclosure. There's not a lot of space and I don't have many good ideas on how to it neatly.

I'll figure something out though (I hope).

Another glamour shot of the 5×2 #handwired #dactyl #keyboard. The middle key in the left column now works as Shift_R (working on modifier keys).

Front of 3D printed keyboard with keys inserted. Two columns have black keycaps. In the background is a breadboard with the microcontroller and many wires connecting the keyboard.

Soldering continues and now I got a working 2×5 button #handwired #keyboard! Implements a6ofdb plus space, backspace and enter!

Breadboard setup with Teensy 2.0 microcontroller and MC23018 I/O expander, all connected to one half of a 3D printed keyboard. Ten of the switches (two columns) have black caps.

Backside of 3D printed keyboard case with keys mounted and diodes soldered in rows. Two of the columns are also soldered with each with a piece of wire.

Finally calling this done! Say hello to the HellSplit a hand-wired, asymmetric 40% split #ortholinear keyboard with vertical column stagger and two rotary encoders. Powered by a pair of Raspberry Pi Pico's #RP2040 and #KMK firmware

#mechanicalkeyboards #splitkeyboard #ergo #otho #mechkb #splitkb #pipico #raspberypipico #40percent #handwired #circuitpython @circuitpython @RaspberryPi @rpimag

Picture of the keyboard on a reflective black surface with fire in the background

Handwired keyboard question:

As I was using my keyboard, suddenly a during a keypress (in the "row" of two keys in the middle) the entire column is being triggered (and flickering). I checked the connections on the keys but I could not find any shorts.

What could this be? Should I resolder everything just to be sure?

#Handwired #MechanicalKeyboard #Dactyl #Manuform #Soldering

Finished my new keyboard! it’s an evolution of my old keyboard with some function keys and media keys moved to the top right so I stop pressing mute instead of ctrl! It is a little taller than I like but the design I layered so I think I can shave off at least 5mm without too much hassle (probably more!)

#3dprinted #3dprinting #olkb #handwired #handwiredkeyboard #ortholinear #ortholinearkeyboard #joescotto #circuitpython #kmk #mechanicalkeyboard #mechanicalkeyboards #polymaker #prusament

Following the failure of my #cyberdeck project, I decided to extract the 3d-printed, hand-wired mechanical keyboard I hand wired and turn it into a standalone jobby. Here’s some before, during and after shots. Just waiting on the USB-C breakout so I can have the cable come from a more sensible direction.

#keyboard #keyboards #mechanicalkeyboard #mechanicalkeyboards #3dprinted #3dprinting #handwiredkeyboard #handwired

Keyboard now in its standalone case (testing rgb)

The moment when the chinese clone is better than original, waveshare RP2040-Zero, it might have less GPIO, but USB-C port is the winner. I have no ideas what was RPI foundation thinking about using micro-usb port in theirs RPI Pico #rpipico #waveshare this will be brain of my next #handwired #keyboard

An electronic circuit board with a blue surface, featuring a USB-C connector, two buttons, and a small LED. The board is positioned on a light-colored surface with a blurred background.

Mes déboires au sujet de la fabrication d’un clavier #handwired sur le #blog
https://mart-e.be/2024/11/construction-d-un-clavier-handwired

I have published the sources of the two (silly) #handwired #keyboard I have made so far

https://git.sr.ht/~mart-e/dactylographe

Woo, after burning two mcu and way too many bad solder joins, I have finished my first #handwired keyboard with #qmk 🥳
Took me way too long to finish but considering that two month ago, I did not know what a diode was and never really used a soldering iron, I am lucky I did not got burned.

picture of a 4x4 macropad, white blank keycaps, wood plate

back of the macropad, can see the wires behind an acrylic sheet

@Vivaldi why the 1337? Realizing #key1337 of course... but, why? Just for fun, or is there a story behind it. How'd I know. Because Oh boy! too much text always!

#Guitar #tubeamplifier #tubeamp #fender #boutique #handwired #handmade
Alley Cat Music store is gone.

I managed their website in the early 2000's. Pics of their all-tube "SRC Barker" amp line, designed by Dr David H Sarge (Fender Deluxe Black Face?).

Mark Ross, owner, passed away in 2020. I learned a lot working there. Rockabilly/Americana players taught me the inspiration of James Burton. Genuine rock-n-roll!

SRC Barker amps are still made, and Mark Ross's legacy lives on. I remember him through "Tanya Browne" and "Queen Bee and the Blue Hornet Band".

The "C" in SRC is for the craftsman who assembled the amps. I can't recall his name, but Mark and Dave were always present. Invaluable knowledge lost likely.

Humans must use emotion as inspiration
#Create
No #DeepLearning #bigdata #DATAset required or able to tell you if it sounds "glassy"

https://whatsonyourbrain.com/superflous-space-and-character/

"Point-to-point" wired, all tube, hand-made amps. I enjoyed curating these images, inspired by vintage calendars. Rockabilly evolved into Americana in the mid-90's.

Alley Cat Music: True stories of Rock ’n Roll!

#vintageampcollectors #rockabilly #americana #guitarhistory #musiclegacy

Left-Hand side of my #diy #handwired 5x6 dactyl manuform #keyboard is partially done.
I soldered in only four shorts on the first try. 🙈
Using amoeba royale pcbs without wanting to use any RGB seemed like it's more work than it's worth, though.

The inside of a hardwired dactyl manuform: A bunch of different colored cables on 'amoeba royale' single key pcbs.

He avanzado un poco con el teclado , soy lo peor con las soldaduras ya lo sé #handwired #keyboard

Base del teclado abierta mostrando cables soldados

Aaaaaand we're done! #customkeyboard #handwired #qmkfirmware

Finished 4x4 3d printed handwired macro pad with blue keycaps, running QMK

Mein erster Eigenbau. Eine handverdrahtete #Redox Splittastatur. Darauf wird jetzt das geliebte #Neo2 geübt, bisher fühlt es sich noch sehr ungewohnt an.

My first build, a #handwired #Redox split keyboard. I'll use it with my beloved #neo2 layout, at the moment it still feels pretty unfamiliar.
#MechanicalKeyboards #3Dprinting #Soldering #qmk

https://github.com/mattdibi/redox-keyboard

Topansicht eine Redox Splittastatur mit unbeschrifteten hellblauen Tasten im Hauptfeld und orangenen und weißen Tasten auf den Sondertasten

Done. #kmk #awesome, love it. My first custom, #diy, #handwired Board.

A few days ago I happened across a mechanical keyboard for sale that was dirt cheap and had actual mechanical switches. I tore them out (after buying it) and have used them in my first keyboard project.

This was just a small test to get a feel for what a full sized keyboard would feel like. But I'm happy with the results. It's essentially a macropad, but I've used KMK with the Artsey.io keyboard layout to turn it into a "proper" keyboard.

I've added more details in the image descriptions.

#keeb #keyboard #mechanical #3dprint #handwired #macropad #kmk

A photo of a Madcats STRIKE keyboard in its box. I got this for $39AUD down from $159-ish. I ended up buying a second one for a Christmas present.

A photo of the Cherry MX Red switches on the keyboard after all the key caps have been pulled off.

A zip lock baggy containing all the desoldered Cherry MX Switches. All up there was about 110 of them.

The underside of the switches in a small 3d printed enclosure, wires have been soldered to the switches but are not connected on the other end. The switches are in a 4 by 2 grid.

I promised #mechanicalkeyboard pics so I better start delivering!

This is the keyboard I built for my campus office, a Dactyl-ManuForm (https://github.com/tshort/dactyl-keyboard) . #3dprinting in Obsidian HTPLA from Protopasta, and #handwired. Uses Kailh box white switches for exceptional clickiness with only mid-weight activation force. Firmware is a customized #qmk .

A split keyboard on a black-and white background. The keys are white with black legends, and the body of the keyboard is black. Each half curves up toward the center, and there is a cluster of 6 keys under the thumbs.

The inside of a keyboard. The body of the keyboard is black, with the bottoms of white keyswitches visible. Silver wires run horizontally across the keyswitches, red wires run vertically. At the top left, all wires come together into a small box.

The left half of a split keyboard on a black and white background. The keys are white with black legends, and the body of the keyboard is black. The keys are in a concave arrangement, and slope up from left to right. A small cluster of six keys dips down and to the right where the thumb is placed.
