A Guide To Using Triacs For Switching AC

https://web.brid.gy/r/https://hackaday.com/2026/01/18/a-guide-to-using-triacs-for-switching-ac/

<div><img alt="" class="attachment-large size-large wp-post-image" height="450" src="https://hackaday.com/wp-content/uploads/2026/01/triac-main.png?w=800" style="margin: 0 auto; margin-bottom: 15px;" width="800" /></div><p>For switching high-powered loads from a microcontroller, or for switching AC loads in general, most of us will reach into the parts bin and pull out a generic relay of some sort. Relays are fundamental, proven technologies to safely switch all kinds of loads. They do have their downsides, though, so if you need silent operation, precise timing, or the ability to operate orders of magnitude more times you might want to look at a triac instead. These solid state devices can switch AC loads unlike other transistor-based devices <a href="https://opensprinkler.com/using-triacs-to-switch-24-vac-sprinkler-solenoids/" target="_blank">and [Ray] at OpenSprinkler is here to give us an overview on how to use them</a>.</p>
<p>The key to switching an AC load is bi-directional conductivity. A normal transistor or diode can only conduct in one direction, so if you try to switch an AC load with one of these you’ll end up with what essentially amounts to a bad rectifier. Triacs do have a “gate” analogous to the base of a bipolar junction transistor, but the gate will trigger the triac when current flows in either direction as well. The amount of current needed to trigger the triac does depend on the state of the switched waveform, so it can be more complex
